PostgreSQL Connector > Mappings and mapping tasks with PostgreSQL Connector > Configuring key range partition


Configuring key range partition

Configure key range partition to partition PostgreSQL data based on field values. Key range is supported for only the numeric and date/time data types.
    1In Source Properties, click the Partitions tab.
    2Select the required Partition Key from the list.
    3Click Add New Key Range to add partitions.
    The following image displays the details of the Partitions tab. The Edit Partition Point dialog box shows Partition#1 and Partition#2. Partition#2 is selected. At the bottom of the dialog box is the partition type selection list. Key Range is selected.
    4Specify the Start range and End range.
