Data Quality Rule Template

A Data Quality Rule Template asset is the business representation of a data quality rule specification. You can use a data quality rule template to create a data quality rule. The actual data quality score of data elements are expressed as Data Quality Rule Occurrences in Data Governance and Catalog. As data quality rules set business expectations, they are often associated with glossary assets such as Business Terms and Metrics.
The following table describes the columns where you must enter asset values for data quality rule templates:
Column
Type
Description
Reference ID
Optional
Reference ID is the unique reference identifier for the asset. If you don't specify a reference ID, the system automatically assigns a unique value to the object.
The identifier that you enter here appears in the Reference ID field on the user interface.
The system uses the following format to generate a reference ID:
<Prefix>-<Number>
Example: ‘DQT-1’, ‘DS-10’
If you specify a reference ID, ensure that the value that you enter doesn’t use the format that is used by the system to automatically generate reference IDs.
Type of Entry: Alphanumeric characters, including spaces and special characters. There is no limitation on special characters to be used in names.
Example: ‘DQ ID-18’, ‘DQT REF:98’
Name
Required
Name for the asset. Consider entering a unique name so that you can distinguish this asset from other assets.
Type of Entry: Alphanumeric characters, including spaces and special characters. There is no limitation on special characters to be used in names.
Example: ‘Data Quality Rule 1’, ‘Completeness Rule Template:29’, ‘Email Address Validity’
Description
Optional
Definition of the asset. The description appears in the asset page.
You can enter a detailed description of the asset so that users can understand how it is used in your governance context.
Type of Entry: Formatted text.
To add an image to the description, use the following syntax:
You can add only an image of Base64 format to the description. Other image formats are not supported.
Criticality
Optional
Select the criticality of the rule template.
You can select one of the following options:
  • - High. The level of impact for a data quality issue is high if there is a high risk of operational, customer, regulatory and financial impact.
  • - Medium. The level of impact for a data quality issue is medium if there is a moderate risk of operational, customer, regulatory and financial impact.
  • - Low. The level of impact for a data quality issue is low if there is a low risk of operational, customer, regulatory and financial impact.
Dimension
Required
Specify the data quality dimension for which the data quality rule is run.
You can select one of the following options:
  • - Accuracy. Data Accuracy refers to the degree to which data can accurately demonstrate the real-world entities.
  • - Validity. Validity dimension signifies the data values that follow a specific format or align with business rules.
  • - Completeness. Completeness dimension suggests if the data fulfills the minimum essential information criteria to deliver meaningful inferences.
  • - Consistency. Consistency dimension indicates if the information stored and utilized in multiple instances is conflicting with itself.
  • - Uniqueness. Data Uniqueness is a measurement to identify and remediate duplication and overlaps.
  • - Timeliness. Timeliness dimension indicates the timely availability of the required and valid data.
Note: If the data quality dimensions listed here differ from what is available in the predefined Microsoft Excel template, the administrator may have defined a different list of dimensions for your organization. For more information about how your administrator can customize the data quality dimensions, see the Administration help in Metadata Command Center.
Enable Automation
Optional
Enable or disable data quality rule automation for the rule template.
You can select one of the following values:
  • - TRUE. Create rule occurrences automatically for data elements that are linked to the associated Glossary assets.
    • After the bulk import job, Data Governance and Catalog initiates a job to create schedules for the Catalog Source. The rule occurrences are created as per the schedule each time the data quality job runs. The frequency of the data quality rule execution depends on the frequency set in the Frequency column of the rule template file.
  • - FALSE. No automated rule occurrences are generated. You can manually run the data quality rule for the associated data elements.
Note: If automation was previously enabled on a rule template, then you cannot use a bulk import template to modify the value from True to False.
Frequency
Optional
Select the frequency of running the data quality rules in the rule template.
You can select one of the following options:
  • - Daily. The schedule for data quality rule run gets repeated every day.
  • - Weekly. The schedule for data quality rule run gets repeated once every week.
  • - Monthly. The schedule for data quality rule run gets repeated once every month.
Lifecycle
Optional
Lifecycle status of the asset. The default status is Published.
You can select one of the following options:
  • - Draft. Typically used when you are creating a fresh asset.
  • - In Review. Typically used when an asset is being reviewed by stakeholders.
    • Note: Informatica recommends that you don't use a bulk import template to set an asset lifecycle to In Review.
  • - Published. Typically used when an asset has been reviewed and accepted by stakeholders and is ready for use by the wider organization.
Measuring Method
Required
Specify the method by which the data quality rules for the rule occurrence are evaluated.
You can select one of the following options:
  • - Business extract. This rule is measured on the data that is exported for a particular business case.
  • - System function. This rule is measured by the data quality system.
  • - Technical script. This rule is measured by a script that is manually run by an analyst.
  • - Informatica Cloud Data Quality. This rule is measured by Informatica Cloud Data Quality service.
If you select Informatica Cloud Data Quality as the measuring method, ensure that you use the Technical Rule Reference field to specify the identifier of the data quality rule that is defined in Informatica Cloud Data Quality. If you don't specify the data quality rule identifier, the bulk import process fails.
Input Port Name
Optional
Specify the input port name on which the data quality rule specification is run.
The primary data element must have only one input port.
Type of Entry: Formatted text
Ouput Port Name
Optional
Specify the output port name on which the data quality rule specification is run.
The primary data element must have only one output port.
Type of Entry: Formatted text
Technical Description
Optional
Specify the technical parameters of the rule definition.
Type of Entry: Formatted text
Technical Rule Reference
Required
Specify the internal ID of the rule specification in the data quality system that you want to run on the data elements.
Type of Entry: Alphanumeric characters, including spaces and special characters. There is no limitation on special characters to be used in rule references.
Target
Required
Specify the minimum acceptable data quality value for the asset to be considered "Good".
Type of Entry: Numeric value. Enter a value between 0 to 100 without the percent sign.
Example: 90 means on or above 90%. This is the target threshold to be achieved.
Threshold
Required
Specify the minimum acceptable data quality value for an asset to be considered as "Acceptable".
Type of Entry: Numeric value. Enter a value between 0 to 100 without the percent sign.
Primary Glossary
Required
Enter the name or reference ID of the Glossary asset that applies to the data quality rule template.
Specify the Glossary asset that represents the data elements on which single port data quality rules in the rule template apply. You can add only one primary glossary to a data quality rule template.
Field Type: Required
Type of Entry: Reference ID or the name of the primary Glossary asset
Example: Email Address, BT-12
Secondary Glossary
Optional
Enter the name or reference ID of the Glossary asset that applies to the data quality rule template.
Specify the Glossary asset represents the data elements on which multi-port data quality rules in the rule template apply. You can enter the names or reference IDs of multiple secondary glossaries separated by semicolons in a single line without any spaces.
Field Type: Optional
Type of Entry: Reference ID or the name of the secondary glossary asset
Example: Marketing Email;Personal Email
Operation
Required
Select an operation for the asset.
You can select one of the following options:
  • - Create. You want to create the asset.
  • - Update. You want to modify an existing asset. In this case, the Reference ID column is mandatory, along with the columns that you want to modify. For example, if you want to modify the Lifecycle of an asset, you must enter the Reference ID and Lifecycle values, but you don't need to specify values for the other fields, including the fields that are marked as mandatory.
  • - Delete. You want to delete an existing asset. In this case, the Reference ID is the only column that is mandatory. You don't need to specify values for any field, including mandatory fields. Before you delete an asset, ensure that you have removed or deleted all associated relationships and parent-child relationships of the asset.
Stakeholder: Governance Administrator
Optional
User or user group that you want to assign as stakeholders of the asset under the Governance Administrator role. If you enter the name of the user, the user becomes a stakeholder of the asset. If you enter a user group here, all users that belong to the user group become stakeholders of the asset. You can also remove a user or user group as a stakeholder of the asset.
Ensure that the users or user groups that you specify are already assigned the relevant user role. For example, to add a user as a stakeholder with the Governance Owner stakeholder role on an asset, the user must already be assigned the Governance Owner user role from the Administrator console.
Type of Entry: Email address of the user, first name followed by the last name with a space in between, or last name followed by comma then the first name, without any spaces in between. To enter multiple values, use a semicolon to separate each value. Do not use a space to separate different values.
If you want to add a user and a user group as the stakeholders of an asset, ensure that you enter the user names and the user group names in separate rows.
To add a stakeholder, you can optionally prefix the term ADD: to the user or user group. To remove a stakeholder, you must mandatorily prefix the term DELETE: to the user or user group.
Examples:
To add users: “steve@yourorg.com;John Admin;Rhodes,Jane”
To add users using the ADD prefix: “ADD:steve@yourorg.com;John Admin;Rhodes,Jane”
To remove users using the DELETE prefix: “DELETE:steve@yourorg.com;John Admin;Rhodes,Jane”
Stakeholder: (Stakeholder role name)
Optional
User or user group that you want to assign as stakeholders of the asset under the (Stakeholder role name) stakeholder role. If you enter the name of the user, the user becomes a stakeholder of the asset. If you enter a user group here, all users that belong to the user group become stakeholders of the asset. You can also remove a user or user group as a stakeholder of the asset.
Ensure that the users or user groups that you specify are already assigned the relevant user role. For example, to add a user as a stakeholder with the Governance Owner stakeholder role on an asset, the user must already be assigned the Governance Owner user role from the Administrator console.
Type of Entry: Email address of the user, first name followed by the last name with a space in between, or last name followed by comma then the first name, without any spaces in between. To enter multiple values, use a semicolon to separate each value. Do not use a space to separate different values.
If you want to add a user and a user group as the stakeholders of an asset, ensure that you enter the user names and the user group names in separate rows.
To add a stakeholder, you can optionally prefix the term ADD: to the user or user group. To remove a stakeholder, you must mandatorily prefix the term DELETE: to the user or user group.
Examples:
To add users: “steve@yourorg.com;John Admin;Rhodes,Jane”
To add users using the ADD prefix: “ADD:steve@yourorg.com;John Admin;Rhodes,Jane”
To remove users using the DELETE prefix: “DELETE:steve@yourorg.com;John Admin;Rhodes,Jane”
The template displays all the stakeholder roles that are relevant for the asset. For more information about stakeholder roles, see the Asset Management help.
Note: If you connect Data Governance and Catalog to Data Quality, perform the following steps to identify the value that you must enter in the Technical Rule Reference field:
  1. 1In Data Quality, open the rule specification for which you want to identify the internal ID.
  2. 2In the address bar of the browser, locate the string that appears after the last slash. This string is the internal ID of the rule specification.
    3. The following image shows the internal ID for a rule specification:
    Image depicting the internal ID for a rule specification in Informatica Cloud Data Quality.
  3. 3Copy the string so that you can paste it into the Technical Rule Reference field.
